Features:

Model: EM7430(DW5816e)

Category: 4G module

Manufacturer: Sierra Wireless

Chipset: Qualcomm MDM9230

Shape: PCIe M.2

Pin: 52 pins

band

- LTE FDD: Bands B1, B3, B5, B7, B8, B18, B19, B21, B28, B38, B39, B40, B41

-UMTS / HSPA +: B1, B5, B6, B8, B9, B19

-TD-SCDMA B39

 Technology: UMTS, HSDPA, HSPA +, LTE

Maximum download speed: 300 Mbps

Maximum upload speed: 50 Mbps

Temperature: -10oC to 55oC

Certification / Supervision: Program: JRF / JPA, NCC

Operator approval: Plan: docomo, Telstra

Connector: Aux / GNSS, GNSS

Satellite system: GPS, Glonass, Beidou, Galileo

Mode: Independent, SUPL 2.0, XTRA 3.0

Control options: API, AT command

Voltage: 1.8V

Active antenna control: 4 pins

Dynamic power control: 1 pin

Interface: "USB 3.0, USB 2.0 High Speed"

SIM interface: 2 x 1.8v or 3v

Audio: PCM / I2S **

 Other interfaces: primary radio disabled, GNSS disabled, flash LED output, WAN wakeup, reset

Size: 42 x 30 x 2.3 mm

Package Included:

1 x EM7430 4G module
